For Safety & Ease Of Use, The ABLE LGT8000X Is A Must Have:
With its clear high lux ability the LGT8000X lighting tower is a must have addition for applications like:
– Mine Sites
– Road Works
– Construction
– Private Functions
– Accident Recovery
– Carnivals & Showgrounds
– Fire & Emergency Services
– Any Location Where Safety And Clear Bright Light Is Paramount.
Just looking over its specifications list it is easy to see why it is the lighting tower of choice.
|
Prime Power : |
12kW / 12kVA 240 Volts 50Amps |
|
Standby Power : |
13kW / 13kVA |
|
Power Factor : |
1 |
|
Phase Voltage : |
Single Phase 240 Volt |
|
Frequency : |
50 Hertz |
|
Engine : |
OEM 4 Cylinder Diesel |
|
RPM : |
1500/min |
|
Cooling Method : |
Water Cooled – Rated For Australia’s North |
|
Alternator : |
Single Phase 4 Pole Brushless Synchronous -/c AVR |
|
Starter System : |
12 volt Electric – Battery Included |
|
Controller : |
Smartgen HGM7120 Series |
|
|
2 Wire / Remote Start Capable |
|
|
Over Temperature Protection |
|
|
Over Current Protection |
|
|
Low Oil Protection |
|
Safety Systems : |
Battery Isolator |
|
Starter Motor Isolator |
|
|
|
Emergency Stop |
|
|
Failsafe Shutdown Fuel Solenoid |
|
Noise Level : |
72 dBA at 7 metres |
|
Fuel Tank Capacity : |
115 Litres (Low Fuel Warning Beacon) |
|
Running Time : |
52 Hours Continuous (prime load) |
|
Fuel Consumption : |
2.2 Litres/Hour (Not Including Auxillary Plug Use) |
|
Chassis Enclosure : |
Lockable |
|
|
Sound Deadening Throughout |
|
|
Weather Resistant Powder Coating |
|
2 x Interior Work Light |
|
|
|
External Use |
|
Mine Site Ready Bunding : |
Yes |
|
ATS (Mains Failure) : |
No |
|
Single Phase Outlets : |
1 x 15 Amp IP66 |
|
Three Phase Outlets : |
No |
|
Hardwire Terminals : |
No |
|
RCD : |
Australian Standard (IP67 Enclosed) |
|
Stanchion/Tower / Mast : |
3 Section 9m Extension (Adjustable Friction) |
|
Extension Mechanism : |
Low Maintenance Easy Action Mechanical Winch |
|
Elevation Height (mm) : |
9140 |
|
Single Phase Outlets : |
4 x 15 Amp IP66 |
|
Lights : |
4 x 2000 Watt IP65 Metal Halide Floodlight |
|
Trailer Chassis : |
Motor Vehicle Standards Act 1989 |
|
AS4177.3 2000kg 50mm Ball Override Brake Hitch |
|
|
Cable Handbrake |
|
|
Leaf Spring |
|
|
Solid Axle |
|
|
Offroad Rims 5 x 114.3 PCD |
|
|
Tyres 185/14 |
|
|
7 Pin Flat Connector |
|
|
Road Light Intrusion Protection |
|
|
4 x Mechanical Load Stabilser / Outrigger |
|
|
Options : |
Automatic Start Systems |
|
|
GSM |
|
|
Timer |
|
|
Wireless Remote |
|
|
MinespecPadlock Isolator |
|
Weight (kg) : |
1600 |
|
Dimensions (cm) : |
430 L x 160 W x 191 H (Transport) |
|
|
299 L x 335 W x 910 H (Operation) |
